Victory BX-52RSH Wood Chipper Wood Shredder With Tractor Independant Hydraulic Tank & Pump

(Product No.: V-BX-52RS-H-c)

Mobile Preview: wood-chipper-wood-shredder side view

Mobile Preview: Victory BX-52RSH Wood Chipper Wood Shredder With Tractor Independant Hydraulic Tank & Pump

(Product No.: V-BX-52RS-H-c)

Victory BX-52RSH Wood Chipper Wood Shredder With Tractor Independant Hydraulic Tank & Pump

Name: Victory BX-52RSH Wood Chipper Wood Shredder With Tractor Independant Hydraulic Tank & Pump
Brand: Victory
SKU: V-BX-52RS-H-c
Price: 2298.00 EUR
Availability: InStock

Shipping time:

Available from stock in 44 days

SOON

2.298,00 EUR

Free shipping - all EU countries

incl. 19% tax

Description

BX-52RSH professional tractor wood chipper - shredder system with tractor independant hydraulic system

PTO shaft driven wood chipper with independant hydraulic feeding system for professional and fast processing of wood with up to 15cm in diameter. Suitable for small and medium tractors with 30 to 60hp and Cat I three-point hitch.

The Victory BX-shredders comply with all safety regulations and is CE tested following the 2006/42/EC machine directive.

➤ For small and medium-sized tractors from 30-60 HP
➤ For tractors with cat. I three-point hitch
➤ With hydraulic tank and pump

Including PTO shaft ✓
Free shipping ✓

Assembly of the Victory BX-52RSH

Working with the Victory BX-52RSH

Application of the wood chipper for tractors:

The Victory BX-52RSH wood chipper offers best performance at 40 to 50hp tractor engine power. Wood branches are pulled into the wood shredder with the help of its own hydraulic system, driving the feeding roller, which drags in the wood into the wood chipper. The Victory BX-52RSH offers fast and easy operation. The large safety bracket operates the hydraulic functions (IN - OUT - STOP) of the feeding rollers, so that almost all wood jams can be easily solved by the "reverse" gear. If you plan to use two different tractors with incompatible types of hydraulic oil, the BX52RS-H is the best solution for you.

Technology of the wood chipper:

The new BX-52RSH comes with its own tractor independant hydraulic system including a 8L hydraulic oil tank and a powerfull 200bar pump driving the input roller without the need to use the tractor´s own hydraulic system. Input roller speed is steplessly adjustable for easy adjustment of the chipper´s performance to diameter and type of wood. Smaller diameter can be pulled in and processed faster by the Victory BX-52RSH wood chipper than larger or harder wood diameter.

Four 21cm long knives, made of hardened tooling steel, are mounted on a 16mm wide and 42kg heavy rotor of the BX-52RSH wood chipper. Wood of up to 15cm diameter can be chipped into 1 to 3cm sized pieces. Additionally mounted winglets on the rotor create the necessary air flow needed to guide even difficult material through the chipper. Inside the massive rotor housing additional replaceable branch breakers are mounted to even shred small branches efficiently. The output hopper can be turned by 230° and is able to throw the wood chips up to 6m far. Trailers, containers and big bags can be easily filled. The Victory BX-52RSH has a capacity of up to 7-8m³/h wood chips per hour.

The new foldable and for this size wood chipper extremely wide 66cm input chute can be operated by the new safety bar from all sides of the machine.

For transportation of the chipper, the large input chute can be easily folded up by only one person and can be secured without any tools. By removing only one bolt, you get access to the rotor and knives of the Victory BX-52RSH wood chipper, making maintenance jobs are matter of minutes. The heavy rotor disc creates a very strong air flow with its speciall design winglets, so that stuck material inside the chipper is virtually impossible. Since the hydraulic roller can turn backwards instantly, blocked material in the input chute can be pulled out of the chipper within seconds.

✅ up to 1000 rpm rotor speed

✅ 4 rotor knives cut the wood ûp to 67 times per sec.

✅ PTO shaft with safety shear bolt
✅ tractor independant hydraulic system with tank and pump
✅ rotor housing and feeding roller housing are easy and fast to open

✅ foldable input chute
✅ BX-52RSH is delivered partially assembled

We from Victory Tractor firmly believe that you will not find a better value for money heavy duty tractor wood shredder in the market. Feel free to compare our product to others in the market and we are sure you will agree.

ATTENTION

Partially assembled machines do not contain any fuel , oil or other fluids or grease needed for operation ! BEFORE USING THE MACHINE please carefully read the English user manual.

Technical Data

Technical Data Victory BX-52-RS / BX-52-RSH Wood chipper, hydraulic feeding system
DATA	BX-52-RS	BX-52-RSH
Dimensions (LxWxH) mm (working position)	2180x1350x1650	2180x1350x1650
Dimensions (LxWxH) mm (transport)	1770x1350x1650	1770x1350x1650
total weight incl. PTO shaft kg	335	355
3-point hitch tractor	Cat 1
PTO shaft turning clockwise RPM	540 ~ 1000 1 3/8" 6T
best result at RPM	1000
PTO shaft safety system	Shear bolt
drive system	direct drive PTO shaft
PTO sharft length mm (included in shipment)	800
Length of hydraulic pipe from 3-point hitch cm	100	-
recommended engine power Tractor hp/KW	30-60 / 22-44
recommended for max. performance hp/KW	40-50 / 30-37
Volume hydraulic tank L	-	9
hydraulic flow speed at 540 RPM L/min	-	6,6
hydraulic flow speed at 1000 RPM L/min	-	12,2
hydraulic pump pressure bar / MPa	-	200 / 20
hydraulic pump max. pressure bar / MPa	-	250 / 25
Rotor diameter cm	59
Rotor width mm	16 + fans
Rotor weight kg	42
numer of knives	4 + 1
size of rotor knives / counter knife cm	21x6x0,9 / 18x6x0,9
adjustment are counter knife mm	0 ~ 5
size of feeding chute - largest (W x H) cm	66 x 50
size of feeding chute - smallest (W x H) cm	17,5 x 13,5
recommended wood diameter cm	< 12
distance from ground to feeding chute lower edge cm	60
distance between feeding roller and rotor knives cm	< 5
expected size of wood chips cm	2 - 3
feeding system	hydraulic in / out
output chute heigt above ground cm	165
output chute turnable	230°
material strength housing mm	6
painting	powder coating
transport box (LxWxH) cm	107x107x106
